When uom Isn't Enough: Addenda

Bonus content from my recent RustWeek talk about unit handling!

As you can see, kilometers are longer than miles. You can tell because 1.609 is larger than 1.

I recently had the pleasure of giving a talk at RustWeek on unit handling.¹ (The talk was recorded, but, at time of writing, the recording has yet to be posted. I'll drop a link here once it's up.) In it, I talked about the uom crate, how awesome it is, and also all of the unit handling challenges that it can't quite solve by itself.

But, at only 15 minutes, there were a lot of juicy details that I sadly had to leave out, so I'm going to talk about them here! I would definitely recommend watching the original talk first, but feel free to read on if you're already familiar with uom and unit handling in general.

Numerical Stability

During the talk, you mentioned some numerical stability issues when converting units. What was the deal with that?

That's a great question, Crane!

To answer it, I'm going to ask you a trick question: If I have a floating point value that's storing a length in kilometers, and I convert it to be in nanometers, should I expect any significant precision loss? (You can assume that my values are of a "normal" magnitude, say 200km)

Hm, my intuition here is no, but I can't quite justify it?

You would be correct! The justification you're looking for is that floating point is built around relative precision. Floating point values give you roughly the same number of significant figures, regardless of what scale you're working in. (As long as you aren't working in any particularly extreme values, like subnormals or infinities.)

As a result, most unit conversions with floating point numbers don't incur significant loss of precision! (Other than the inherent precision loss that you get as a result of floating point drift.)

Here's a follow up question, what about fixed point numbers?

Well, fixed point numbers are basically just integers, where the difference between consecutive values are always a fixed step size. So... it depends?

Correct again! You have to be careful of two things with fixed point:²

1. When converting from large units to small units (like km to nm), then we need to be careful to not overflow our integer
2. When converting from small units to large units, then we need to be careful about losing precision, since "integer nanometers" are much more fine-grained than "integer kilometers"

Cool! Good to know that we don't need to worry too much about precision now, right?

Well...

The Circus of GIS

Puts on clown makeup

GIS stands for "geographic information system" and it is unit handling's cursed, evil older sibling that does drugs. I am not a GIS expert by any stretch of the imagination, but I have heard horror stories from those more experienced than myself.

These systems primarily deal with data that is spatially distributed around the globe: surveying, mapmaking, GPS, large scale construction of all forms, and more. It inherits all of the challenges that normal unit handling has, but it also has extremely tight precision requirements.

How extreme are we talking here?

Let's think about the limits of f64 precision. f64 usually gives you about 16 significant figures of precision, which on this scale lets you represent the surface of the earth down to nanometer precision.

Surely that would be enough for anyone... right? Right?

Bad news, kid.

These people want nanometer precision, which means that if you have any amount of floating point drift, you are boned! True nanometer precision might sound like an absurd requirement, but when your job is literally making the GPS satillite map, you need things to be that precise.

Ok, so either we can't do much math, or we need to use a higher precision format, like fixed point or BigNumber?

Yes, but there's more.

In addition to all these precision problems there are also a great variety of geospatial standards and coordinate reference systems, all of which have their own tradeoffs. Some use cartesian coordinates, some use ellipsoid coordinates, and all of them have slightly different ways of representing the earth's curvature. Additionally, each system has its own tradeoffs regarding local and global accuracy.

And then you have to throw in the wrench that the earth's surface changes over time, and so these reference systems also have to change over time to maintain accuracy.

Goodness, how do you even handle all of that?

Again, I am far from a GIS expert, and you probably shouldn't trust me too much on this. However, from what I've learned from talking with much smarter people:

• You generally want to avoid converting between reference systems unless you absolutely have to
• You should generally trust that your users have chosen their reference frames and standards with intent: they have already evalulated the tradeoffs for their use case
• You are allowed to convert things, but you need to accept that that conversion is destructive
• geodesy is pretty cool and you should probably use it³

Cereal Eyes A Shun

Serializing numbers with unit information is a fun and interesting challenge.

Wait, does uom handle serialization?

It does! The way it handles it is actually related to how uom manages to be zero cost: everything is just metric internally.⁴

I mentioned this in the talk, but uom always converts inputs to a consistent internal unit system on construction:

// Give it a value in inches, and uom converts it inside this constructor
let my_length = Length::new::<inch>(2.54);
// my_length is now internally stored in meters!

Internally, Length doesn't store any unit information; it's just an f64. The unit information only exists at compile time, and conversions are baked in.

As a result, serializing a uom value is a simple as serializing an f64. You just... write down the number. Since the internal representation is always using the same unit, you can always deserialize it back as the same value.

Question: what happens if the "base unit" changes between versions of the software? What if an older version was using centimeters internally, and now the new version uses meters?

Ah... yes...

This is a real problem. When serializing and deserializing, all our unit information is implicit. It's a side effect of the configuration of our program, not something we actually track explicitly. So, if we were in the situation that Crane described, then our program would implicitly assume that the file had always been in meters, and then silently deserialize the wrong value.

So, what do we do?

The same thing we do for all our other serialization backcompat, Pinky :)

This problem isn't limited to just units: it's common in CAD to have save files or project files that need to be backwards-compatible. This includes not just unit system changes, but structural changes to your object model, floating origin shifting, handling defaults for new functionality, and much more. Any CAD software worth its salt will already have some kind of system in place to handle this, and we can just handle our unit system changes by piggybacking on that existing system.

Cool! So... how do we actually do that then?

Serialization backcompat is a fascinating subject!

...That I don't think I have time to talk about today 😅

Story for another time?

Story for another time <3
